Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in making construction equipment. They make machinery like manlifts, boom lifts and aerial lifts. These machinery are designed to facilitate access to hard to reach places, roofs and buildings, large equipment, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration refers to a power-driven endless belt. This belt only moves in one direction and includes handholds or platforms or steps which are attached to the unit to be able to move personnel from each floor.
TB85
The TB85 man lift by Terex offers a max working height at 91 feet. The max height of the platform reaches 85 feet, while the model's maximum width is 8.5 feet. The TB85 has dimensions which measure 9 inches wide and 9 feet, 1-inch high by 36 feet. This model offers a reach of 70 feet. The TB85 has a boom angle above horizontal measuring 75 degrees and below horizontal measures at -14 degrees.
Terex TB100
The maximum height of Terex's TB100 man lift is 106 feet and the maximum height of the platform is 100 feet. The TB100 when stowed away, is approximately 9 feet high by 8.5 feet wide by 8 feet. The unit's maximum width is 8 feet, 1 1/2 inches. The boom angle above horizontal is 75 degrees and below horizontal is 14 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The TB110 has a maximum platform height of 100 feet and the unit's overall maximum working height measures at 116 feet. When stowed, this model is 8 feet wide x 9 feet, 4 inches high. The TB110 provides a horizontal reach of 67 feet and a maximum width of 8 feet. This model has a boom angle of 75 degrees above horizontal plus 10 degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
